€91.23
The price is per 1 piece.
Parameters:
|
Impedance (Z) |
8 Ω |
| Frequency range | f3-5,000 Hz |
| Resonant frequency (fs) | 49 Hz |
| Power rating (RMS) | 60 W |
| Peak music power output (MAX) | 150 W |
| SPL | 88 dB/W/m |
| Suspension compl. (Cms) | 1.0 mm/N |
| Moving mass (Mms) | 10.3 g |
| Mech. Q factor (Qms) | 2.7 |
| Electr. Q factor (Qes) | 0.67 |
| Total Q factor (Qts) | 0.55 |
| Equivalent volume (Vas) | 33 l |
| DC resistance (Re) | 7.2 Ω |
| Force factor (BxL) | 5.80 Tm |
| Voice coil induct. (Le) | 0.6 mH |
| Voice coil diameter | Ø 25.5 mm |
| Voice coil former | aluminium |
| Linear excursion (XMAX) | ± 3 mm |
| Eff. cone area (Sd) | 140 cm2 |
| Magnet weight | 380 g |
| Magnet diameter | Ø 80 mm |
| Mounting cutout | Ø 145 mm |
| Mounting depth | 73 mm |
| Mounting hole diameter | Ø 172 mm |
| Dimensions | Ø 159 mm x 78 mm |
| Outside diameter | Ø 159 mm |
| Width | Ø 159 mm |
| Depth | 78 mm |
| Colour | black |
| Admiss. ambient temp. | 0-40 °C |
| Weight | 0.97 kg |
| Packing unit | 1 |
| Type of speaker | 6.5" |
| Packing dimensions (W x H x L) | 0.175 x 0.11 x 0.175 m |
| Gross weight | 1.09 kg |
| Net weight | 0.97 kg |
Product Details
Specific References
- ean13
- 4007754220964
- mpn
- SPM-165/8
In the same category
Hi-fi dome tweeters, 45 W, 8 Ω (/8) and 4 Ω (/4). Textile dome tweeter with Kapton voice coil former. Excellent radiation pattern due to waveguide. Very well-suited as a replacement for high-quality hi-fi speakers
